Cassette Fan Coil Unit has the high efficient performance and beautiful appearance. 4 air outlets make the supply air softer and people feel more comfortable. It is widely applicated in hotels, restaurants, bars, schools, offices and other commercial places.
| Model | HT-C-34-(EC), HT-C-51-(EC), HT-C-68-(EC), HT-C-85-(EC), HT-C-102-(EC), HT-C-136-(EC), HT-C-170-(EC), HT-C-204-(EC), HT-C-238-(EC), HT-C-272-(EC) |
|---|---|
| Power Supply | 220-240V~/1Ph/50Hz |
| Power Input | 17W-240W |
| Rated Air Flow Volume | 380-2720m³/h |
| Cooling Capacity | 1.84KW-13.80KW |
| Heating Capacity | 1.93KW-14.49KW |
| Controller | Wired Or Remote Control |
The premium model is equipped with a built-in lifting pump, which increases the water flow rate inside the coil, enhancing heat exchange efficiency.
The motor is a high-performance model, ensuring stable operation.
High-density, thickened rubber shock absorbers are installed to reduce noise and vibration during operation.
Seamless copper tubes and new high-efficiency corrugated double-bent fully enclosed hydrophilic aluminum fins optimize flow design and effectively improve heat transfer efficiency.
The premium model is equipped with a built-in lifting pump, which increases the water flow rate inside the coil, enhancing heat exchange efficiency.
The air inlet mesh is secured with a snap-on design, making it easy to remove and clean the filter.
